Yamaha DM3S 22 Channel Digital Mixer

Yamaha DM3S 22 Channel Digital Mixer

Features:

Packs 22 channels into an ultra-compact digital mixer: 16 mono channels, 1 stereo channel, and 2 stereo FX returns
9-inch touchscreen and single all-purpose touch-and-turn knob provide easy operation and navigation
Capable of sampling rates as high as 96kHz
6 mono or 3 stereo mixes, 2 matrixes, and 1 stereo bus
16 outstanding mic preamps and 8 convenient analog outputs
Excellent built-in DSP effects
18 x 18 USB audio interface for playback and recording
2 x 2 recording directly to a USB drive
DAW remote mode with transport control
Custom control via OSC, USB-MIDI, and Yamaha’s powerful ProVisionaire software applications

Specs
Type: Digital Mixer
Channels: 22
Inputs – Mic Preamps: 12 x XLR, 4 x XLR-1/4″ combo
Phantom Power: 16 Channels
Outputs – Main: 8 x XLR
Busses/Groups: Internal (1 x stereo, 6 x mix, 2 x FX, 2 x matrix)
Data I/O: 1 x RJ-45 (LAN)
Headphones: 1 x 1/4″
USB: 1 x Type A, 1 x Type B
Computer Connectivity: USB (18 x 18)
Faders: 9 x 100mm Motorized Faders
A/D Resolution: Up to 96kHz
DAW Control: Yes
Screen: 9″ touchscreen
Storage: USB slot
Power Source: 24V DC, 2.5 Power Supply (included)
Height: 5.5″
Depth: 17.9″
Width: 12.6″
Weight: 14.33 lbs / 6 kgs (not include shipping weight)
Manufacturer Part Number: DM3S
