Sennheiser XSW2 865 Wireless System with Hand Mic

Features:

Excellent live sound featuring Sennheiser’s renowned evolution microphone capsules
True diversity receiver with metal housing
External antennas
Automatic frequency management and synchronisation
Remote channel for easy setup
Fully tuneable over a wide range of UHF frequencies
Rackmount kit included
Up to 12 compatible channels

Specifications

XSW 2-865 System:

Modulation: Wideband FM
Frequency Range: A (548 – 572 MHz)
Switching Bandwidth: up to 24 MHz
Frequencies: adjustable in 25-kHz steps; 8 frequency banks, each with up to 12 factory-preset channels
Signal-to-Noise Ratio: ≥ 103 dBA
THD: ≤ 0.9%
Temperature Range:
Operation: 32° to +104° F | 0° to +40° C
Storage: -4° to +158° F | -20° to +70° C
Transmitter Sychronization: 2.4 GHz, Low Power OQPSK (only active during synchronization)

EM-XSW 2 Receiver:

Receiver Principle: Double Superheterodyne
Diversity Principle: True Diversity
Sensitivity (@ Peak Deviation): < 3 µV at 52 dB(A)rms S/N
AF Frequency Response: 50 to 16,000 Hz (-3 dB)
Max. AF Output Voltage (@ Peak Deviation, 1 kHz AF): 1/4″ (6.3 mm) jack socket (unbalanced): 6 dBu; XLR socket (balanced): +12 dBu
Audio Adjustment Range: 40 dB, adjustable in 5-dB steps
Power Supply: 12 V DC nom. / 300 mA
Squelch: Adjustable from 3 dBµV to 28 dBµV (combined with pilot tone)
Line/Mic Level: 20 dB, switchable
Housing Material: rugged metal housing
Dimensions (W x H x D): 7.87 x 1.65 x 5.0 in | 200 x 42 x 127 mm
Weight: 24 oz | 680 g

SKM 865-XSW 2 Microphone:

RF Output Power: 10 mW
AF Frequency Response: 80 to 16,000 Hz
Power Supply: (2) AA size batteries, 1.5 V
Operating Time: approx. 10 hrs
Microphone Type: Condenser
Pick-Up Pattern: Super-cardioid
Input Sensitivity (Caspsule): 1.8 mV/Pa
Adjustment Range of Transmitter Sensitivity: 0 to -30 dB, adjustable in 10 dB steps
Housing Material: Rugged ABS housing
Dimensions (L x Diameter): 10.2 x 2 in | 260 x 50 mm
Weight: 8.6 oz | 245 g
